T&B LBY35-TB 1" Capped Elbow, Iron, Female/Female, Explosion-Proof

Overview

T&B LBY35-TB 1" Capped Elbow, Iron, Female/Female, Explosion-Proof

Product Specifications

• UPC: 78621068916
• Additional Information: Application Hazardous, Wet Location; Constructional Feature Explosionproof, Dust Ignitionproof, Raintight; Enclosure Type Class I Div 1 and 2 Group C D, Class II Div 1 Group F G, Class III Div 1 and 2, NEMA 3/4/7CD/9E/9F/9G; Cap Size 2-1/2 Inch Dia; Throa
• Catalog Number: LBY35-TB
• Model: LB
• Type: Capped
• Trade Size: 1 Inch
• Bend Angle: 90 Deg
• Connection Type: Female, Female
• Material: Ductile Iron
• Approval: UL
• Catalog Description: 1 INCH HAZARDOUS LOCATION CAPPED ELBOW, DUCTILE IRON
• Category: Steel Sealing Bodies
• Full Technical Description: Capped Type; Ductile Iron Material; Female, Female Connection Type; UL Approval; 1 Inch Trade Size; 90 Deg Bend Angle; Application Hazardous, Wet Location; Constructional Feature Explosionproof, Dust Ignitionproof, Raintight; Enclosure Type Class I Div 1 and 2 Group C D, Class II Div 1 Group F G, Class III Div 1 and 2, NEMA 3/4/7CD/9E/9F/9G; Cap Size 2-1/2 Inch Dia; Throat Size 0.955 to 1.035 Inch; LB Model
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Explosionproof Conduit Elbow
• Unspsc: 39131717
• UPC 12 Digit: 786210689166
• SKU Name: t&b lby35tb

Resources

• Manufacturer Spec Sheet
