Material: PTFE Based Bluekote Coated Zinc Plating Class 30 Gray Iron Alloy Interior, Acrylic Epoxy Coated Zinc Plating Class 30 Gray Iron Alloy Exterior, Neoprene Gasket, Stainless Steel Screw
Form Type: Form 7
Approval: UL 514A, UL 514B, UL E2969, CSA C22.2
Used On: Rigid/IMC Conduit
Additional Information: Includes Cover, Gasket
Catalog Number: TB57CG-TB
Brand Name: BlueKote[R]
Access Opening: Tee Back
Configuration: TB
Cover Type: Stamped Steel
Hub Location: Tee
Number Of Hubs: 3
Hub Size: 1-1/2 Inch
Catalog Description: 1-1/2 INCH FORM 7 (TB) PRE-ASSEMBLED CONDUIT BODY, COVER AND GASKET, BODY MATERIAL GRAY IRON/ZINC PLATING AND BAKED ON EPOXY POWDER COAT WITH BLUEKOTE INTERNAL COATING, COVER MATERIAL AND FINISH STAMPED STEEL/ZINC PLATING
Category: Aluminum Conduit Bodies & Covers
Full Technical Description: PTFE Based Bluekote Coated Zinc Plating Class 30 Gray Iron Alloy Interior, Acrylic Epoxy Coated Zinc Plating Class 30 Gray Iron Alloy Exterior, Neoprene Gasket, Stainless Steel Screw Material; Rigid/Imc Conduit Used on; 1-1/2 Inch Hub Size; Threaded Installation; TB Configuration; 3 Hub(S); UL 514A, UL 514B, UL E2969, CSA C22.2 Approval; Stamped Steel Cover Type; Tee Hub Location; Form 7 Form Type; Tee Back Access Opening; BLUEKOTE[R] Brand; Includes Cover, Gasket
