3M 10006 Scotchlok Copper Standard Barrel Connector, Up To 35 Kv, 2/0 Awg, Black

Overview

3M 10006 Scotchlok Copper Standard Barrel Connector, Up To 35 Kv, 2/0 Awg, Black

Product Specifications

• UPC: 05400712774
• Length: 2 Inch
• Inner Diameter: 0.44 Inch
• Outer Diameter: 0.56 Inch
• Body Material: Electro Tin Plated Copper
• Approval: UL, CSA
• Additional Information: RoHS Compliant; Temperature Rating 105 Deg C; Application Indoor/Outdoor
• Catalog Number: 10006
• Brand Name: Scotchlok[TM]
• Model: 10000
• Voltage Rating: 35 Kilovolt
• Conductor Size: 2/0 AWG
• Conductor Material: Copper
• Color Code: Black
• Barrel Type: Standard
• Catalog Description: THEY ARE DESIGNED TO CONNECT COPPER CONDUCTORS. EACH CONNECTOR IS ELECTRO-TIN PLATED TO RESIST ELECTROLYTIC CORROSION. THEY ARE INSTALLED USING STANDARD INDUSTRY TOOLING. CHAMFERED ENDS AND AN INTEGRAL CENTER CABLE STOP ENSURE SIMPLICITY AND EASE OF CONDUCTOR INSERTION.
• Category: Large Terminals & Connectors
• Full Technical Description: 2 Inch; 0.44 Inch Inner Diameter; 0.56 Inch Outer Diameter; Copper Conductor Material; UL, CSA Approval; 35 Kilovolt Voltage Rating; Electro Tin Plated Copper Body Material; 2/0 AWG Conductor Size; Black Color Code; Standard Barrel Type; RoHS Compliant; Temperature Rating 105 Deg C; Application Indoor/Outdoor; 10000 Model
• Manufacturer: 3M Co.
• Manufacturer Brand: 3M Electrical Products
• Sub Category: Compression Cable Splice
• Unspsc: 27121707
• UPC 12 Digit: 054007127741
• SKU Name: 3m 10006
