3M 11007 Scotchlok Copper Long-Barrel Connector, Up To 35 Kv, 3/0 Awg, Orange

Overview

3M 11007 Scotchlok Copper Long-Barrel Connector, Up To 35 Kv, 3/0 Awg, Orange

Product Specifications

• UPC: 05400712808
• Barrel Type: LONG BARREL
• Length: 3.13 INCH
• Length In Inch: 3.13
• Inner Diameter: 0.49 INCH
• Outer Diameter: 0.617 INCH
• Body Material: COPPER
• Approval: UL 486-A, UL 486-B, CSA
• Additional Information: PACKAGING QUANTITY 10 PER CASE; APPLICATION INDOOR/OUTDOOR
• Catalog Number: 11007
• Brand Name: Scotchlok[T]
• Model: 11000
• Type: CENTER WIRE STOP
• Voltage Rating: 35 KV
• Conductor Size: 3/0 AWG
• Conductor Material: COPPER
• Color Code: ORANGE
• Catalog Description: THE 3M SCOTCHLOK CONNECTORS 20000 SERIES CAN BE USED WITH EITHER COPPER OR ALUMINUM CONDUCTORS. THESE ALUMINUM CONNECTORS FEATURE COLOR CODED END CAPS FOR IDENTIFICATION. CONTACT AID PROVIDED IN CONNECTOR IS COMPATIBLE WITH POLY/EPR INSULATIONS. EACH CONNECTOR IS ELECTRO TIN PLATED TO RESIST ELECTROLYTIC CORROSION, AND HAVE A SOLID CENTER STOP. (UL 486B LISTED)
• Category: Large Terminals & Connectors
• Full Technical Description: Center Wire Stop Type; 3.13 Inch; 3.13 Length in Inch; 0.49 Inch Inner Diameter; 0.617 Inch Outer Diameter; Copper Conductor Material; UL 486-A, UL 486-B, CSA Approval; 35 kV Voltage Rating; Copper Body Material; 3/0 AWG Conductor Size; Orange Color Code; Long Barrel Barrel Type; SCOTCHLOK[T] Brand; Packaging Quantity 10 Per Case; Application Indoor/Outdoor; 11000 Model
• Manufacturer: 3M Co.
• Manufacturer Brand: 3M Electrical Products
• Sub Category: Compression Cable Splice
• Unspsc: 27121707
• UPC 12 Digit: 054007128083
• SKU Name: 3m 11007
