3M 11014 Scotchlok Copper Long-Barrel Connector, Up To 35 Kv, 500 Kcmil, Brown

Overview

3M 11014 Scotchlok Copper Long-Barrel Connector, Up To 35 Kv, 500 Kcmil, Brown

Product Specifications

• UPC: 05400712907
• Length: 4.63 Inch
• Inner Diameter: 0.84 Inch
• Outer Diameter: 1.06 Inch
• Body Material: Electro Tin Plated Copper
• Approval: UL, CSA
• Additional Information: RoHS Compliant; Used On 5420/5461/5450 Series Splice Kit
• Catalog Number: 11014
• Brand Name: Scotchlok[TM]
• Model: 11000
• Voltage Rating: 35 Kilovolt
• Conductor Size: 500 KCMIL
• Conductor Material: Copper
• Color Code: Brown
• Barrel Type: Long
• Catalog Description: THE 3M SCOTCHLOK CONNECTORS 20000 SERIES CAN BE USED WITH EITHER COPPER OR ALUMINUM CONDUCTORS. THESE ALUMINUM CONNECTORS FEATURE COLOR CODED END CAPS FOR IDENTIFICATION. CONTACT AID PROVIDED IN CONNECTOR IS COMPATIBLE WITH POLY/EPR INSULATIONS. EACH CONNECTOR IS ELECTRO TIN PLATED TO RESIST ELECTROLYTIC CORROSION, AND HAVE A SOLID CENTER STOP. (UL 486B LISTED)
• Category: Large Terminals & Connectors
• Full Technical Description: 4.63 Inch; 0.84 Inch Inner Diameter; 1.06 Inch Outer Diameter; Copper Conductor Material; UL, CSA Approval; 35 Kilovolt Voltage Rating; Electro Tin Plated Copper Body Material; 500 kcmil Conductor Size; Brown Color Code; Long Barrel Type; RoHS Compliant; Used on 5420/5461/5450 Series Splice Kit; 11000 Model
• Manufacturer: 3M Co.
• Manufacturer Brand: 3M Electrical Products
• Sub Category: Compression Cable Splice
• Unspsc: 27121707
• UPC 12 Digit: 054007129073
• SKU Name: 3m 11014
