3M 20007 Scotchlok Aluminum Connector, Up To 35 Kv, 3/0 Awg, Ruby

Overview

3M 20007 Scotchlok Aluminum Connector, Up To 35 Kv, 3/0 Awg, Ruby

Product Specifications

• UPC: 05400713293
• Barrel Type: Standard Barrel
• Length: 2.62 Inch
• Inner Diameter: 0.48 Inch
• Outer Diameter: 0.76 Inch
• Body Material: Aluminum
• Approval: UL 486-A/486-B
• Additional Information: Application Indoor, Outdoor; Operating Temperature 90 Deg C
• Catalog Number: 20007
• Brand Name: Scotchlok[TM]
• Model: 20000
• Type: Center Wire Stop
• Voltage Rating: 35 KV
• Conductor Size: 3/0 AWG
• Conductor Material: Copper/Aluminum
• Color Code: Ruby
• Catalog Description: THE 3M SCOTCHLOK CONNECTORS 20000 SERIES CAN BE USED WITH EITHER COPPER OR ALUMINUM CONDUCTORS. THESE ALUMINUM CONNECTORS FEATURE COLOR CODED END CAPS FOR IDENTIFICATION. CONTACT AID PROVIDED IN CONNECTOR IS COMPATIBLE WITH POLY/EPR INSULATIONS. EACH CONNECTOR IS ELECTRO TIN PLATED TO RESIST ELECTROLYTIC CORROSION, AND HAVE A SOLID CENTER STOP. (UL 486B LISTED)
• Category: Large Terminals & Connectors
• Full Technical Description: Center Wire Stop Type; 2.62 Inch; 0.48 Inch Inner Diameter; 0.76 Inch Outer Diameter; Copper/Aluminum Conductor Material; UL 486-A/486-B Approval; 35 kV Voltage Rating; Aluminum Body Material; 3/0 AWG Conductor Size; Ruby Color Code; Standard Barrel Barrel Type; Application Indoor, Outdoor; Operating Temperature 90 Deg C; 20000 Model
• Made In Usa: Yes
• Manufacturer: 3M Co.
• Manufacturer Brand: 3M Electrical Products
• Sub Category: Compression Cable Splice
• Unspsc: 27121707
• UPC 12 Digit: 054007132936
• SKU Name: 3m 20007
