T&B 60542 Copper Tin Plated 2-Way Connector Splice Standard 3/0 Ruby

Overview

T&B 60542 Copper Tin Plated 2-Way Connector Splice Standard 3/0 Ruby

Product Specifications

• UPC: 78621060542
• Outer Diameter: 0.77 Inch
• Body Material: High Conductivity Electro Tin Plated Wrought Aluminum
• Approval: UL, CSA
• Additional Information: Die Code 60; Temperature Rating 90 Deg C
• Catalog Number: 60542
• Type: 2-Way
• Voltage Rating: 600 Volt to 35 Kilovolt
• Conductor Size: 3/0 AWG
• Conductor Material: Aluminum/Copper
• Color Code: Ruby
• Barrel Type: Standard
• Length: 2.81 Inch
• Catalog Description: TWO-WAY ALUMINUM SPLICE CONNECTOR, WIRE SIZE 3/0, DIE CODE 60, DIE COLOR CODE RUBY
• Category: Large Terminals & Connectors
• Full Technical Description: 2-Way Type; 2.81 Inch; 0.77 Inch Outer Diameter; Aluminum/Copper Conductor Material; UL, CSA Approval; 600 Volt to 35 Kilovolt Voltage Rating; High Conductivity Electro Tin Plated Wrought Aluminum Body Material; 3/0 AWG Conductor Size; Ruby Color Code; Standard Barrel Type; Die Code 60; Temperature Rating 90 Deg C
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Compression Cable Splice
• Unspsc: 39121449
• UPC 12 Digit: 786210605425
• SKU Name: t&b 60542
