3M 20010 Scotchlok Aluminum Connector, Up To 35 Kv, 300 Kcmil, Dark Blue

Overview

3M 20010 Scotchlok Aluminum Connector, Up To 35 Kv, 300 Kcmil, Dark Blue

Product Specifications

• UPC: 05400713327
• Barrel Type: Standard Barrel
• Length: 3.12 Inch
• Inner Diameter: 0.65 Inch
• Outer Diameter: 1 Inch
• Body Material: Aluminum
• Approval: UL 486-A/486-B
• Additional Information: Application Indoor, Outdoor; Operating Temperature 90 Deg C
• Catalog Number: 20010
• Brand Name: Scotchlok[TM]
• Model: 20000
• Type: Center Wire Stop
• Voltage Rating: 35 KV
• Conductor Size: 300 KCMIL
• Conductor Material: Copper/Aluminum
• Color Code: Dark Blue
• Catalog Description: THE 3M SCOTCHLOK CONNECTORS 20000 SERIES CAN BE USED WITH EITHER COPPER OR ALUMINUM CONDUCTORS. THESE ALUMINUM CONNECTORS FEATURE COLOR CODED END CAPS FOR IDENTIFICATION. CONTACT AID PROVIDED IN CONNECTOR IS COMPATIBLE WITH POLY/EPR INSULATIONS. EACH CONNECTOR IS ELECTRO TIN PLATED TO RESIST ELECTROLYTIC CORROSION, AND HAVE A SOLID CENTER STOP. (UL 486B LISTED)
• Category: Large Terminals & Connectors
• Full Technical Description: Center Wire Stop Type; 3.12 Inch; 0.65 Inch Inner Diameter; 1 Inch Outer Diameter; Copper/Aluminum Conductor Material; UL 486-A/486-B Approval; 35 kV Voltage Rating; Aluminum Body Material; 300 kcmil Conductor Size; Dark Blue Color Code; Standard Barrel Barrel Type; Application Indoor, Outdoor; Operating Temperature 90 Deg C; 20000 Model
• Made In Usa: Yes
• Manufacturer: 3M Co.
• Manufacturer Brand: 3M Electrical Products
• Sub Category: Compression Cable Splice
• Unspsc: 39120000
• UPC 12 Digit: 054007133278
• SKU Name: 3m 20010
