3M 31156 Scotchlok Copper 2-Hole Long Barrel Lug, Up To 35 Kv, 350 Kcmil, Red

Overview

3M 31156 Scotchlok Copper 2-Hole Long Barrel Lug, Up To 35 Kv, 350 Kcmil, Red

Product Specifications

• UPC: 05400712667
• Pad Size: 3 Inch Length x 1.13 Inch Width
• Number Of Pad Holes: 2
• Pad Hole Spacing: 1.75 Inch
• Stud Size: 1/2 Inch
• Color: Red
• Material: Tin Plated Copper
• Overall Length: 5.75 Inch
• Approval: UL, CSA
• Additional Information: RoHS Compliant; Outer Diameter 0.87 Inch; Used On Copper Conductor
• Catalog Number: 31156
• Brand Name: Scotchlok[TM]
• Model: 31100
• Voltage Rating: 35 Kilovolt
• Conductor Material: Copper
• Conductor Size: 350 KCMIL
• Barrel Type: Long
• Barrel Length: 1.94 Inch
• Catalog Description: 3M SCOTCHLOK 31100 2 HOLE COMPRESSION LUG IS FOR USE WITH COPPER CONDUCTORS ONLY. THE SEAMLESS COPPER CONSTRUCTION OFFERS HIGH CONDUCTIVITY AND A TIN PLATED FINISH RESISTS CORROSION. IT IS RATED FOR 35 KV VOLTAGE APPLICATIONS.
• Category: Large Terminals & Connectors
• Full Technical Description: Tin Plated Copper Material; Red Color; 5.75 Inch Overall Length; 1.94 Inch Barrel Length; Copper Conductor Material; UL, CSA Approval; 35 Kilovolt Voltage Rating; 350 kcmil Conductor Size; 1/2 Inch Stud Size; 3 Inch Length X 1.13 Inch Width Pad Size; 2 Pad Hole(S); 1.75 Inch Pad Hole Spacing; Long Barrel Type; RoHS Compliant; Outer Diameter 0.87 Inch; Used on Copper Conductor; 31100 Model
• Manufacturer: 3M ELECTRICAL MARKET ELECTRICAL PRODUCTS
• Manufacturer Brand: 3M Electrical Products
• Sub Category: Compression Cable Lug
• Unspsc: 27121707
• UPC 12 Digit: 054007126676
• SKU Name: 3m 31156
