3M 40024 Scotchlok Aluminum 1-Hole Lug, Up To 35 Kv, 2 Awg, Pink
Product Specifications
UPC: 05400713426
Pad Size: 1.03 Inch L x 0.75 Inch W
Number Of Pad Holes: 1
Stud Size: 3/8 Inch
Color: Pink
Die Index: 163/348
Material: Aluminum
Overall Length: 2.62 Inch
Approval: UL, CSA
Additional Information: Inside Diameter 0.3 Inch; Outside Diameter 0.53 Inch; Used On Aluminum/Copper Conductor; Application Indoor, Outdoor; Operating Temperature 90 Deg C
Catalog Number: 40024
Brand Name: Scotchlok[TM]
Model: 40000
Voltage Rating: 35 KV
Conductor Material: Aluminum/Copper
Conductor Size: 2 AWG
Barrel Type: Standard
Barrel Length: 0.92 Inch
Catalog Description: 3M SCOTCHLOK 40000 1 HOLE COMPRESSION LUG IS SUITABLE FOR USE ON COPPER OR ALUMINUM CONDUCTORS. THE LUG HAS A STANDARD BARREL THAT ENSURES A SECURE FIT. ALUMINUM CONSTRUCTION OFFERS HIGH CONDUCTIVITY AND AN ELECTRO TIN PLATED FINISH RESISTS CORROSION. IT IS RATED FOR 35 KV VOLTAGE APPLICATIONS.
Category: Large Terminals & Connectors
Full Technical Description: Aluminum Material; Pink Color; 2.62 Inch Overall Length; 0.92 Inch Barrel Length; Aluminum/Copper Conductor Material; UL, CSA Approval; 35 kV Voltage Rating; 2 AWG Conductor Size; 3/8 Inch Stud Size; 163/348 Die Index; 1.03 Inch L X 0.75 Inch W Pad Size; 1 Pad Hole(S); Standard Barrel Type; Inside Diameter 0.3 Inch; Outside Diameter 0.53 Inch; Used on Aluminum/Copper Conductor; Application Indoor, Outdoor; Operating Temperature 90 Deg C; 40000 Model
