3M 40153 Scotchlok Aluminum 2-Hole Lug, Up To 35 Kv, 300 Kcmil Awg, Dk Blue
Product Specifications
UPC: 05400713657
Pad Size: 3.56 Inch L x 1.38 Inch W
Number Of Pad Holes: 2
Pad Hole Spacing: 1.75 Inch
Stud Size: 1/2 Inch
Color: Dark Blue
Die Index: 251/470
Material: Aluminum
Overall Length: 6.56 Inch
Approval: UL
Additional Information: Inside Diameter 0.65 Inch; Outside Diameter 1 Inch; Used On Aluminum/Copper Conductor; Application Indoor, Outdoor; Operating Temperature 90 Deg C
Catalog Number: 40153
Brand Name: Scotchlok[TM]
Model: 40000
Voltage Rating: 35 KV
Conductor Material: Aluminum/Copper
Conductor Size: 300 KCMIL
Barrel Type: Standard
Barrel Length: 2.25 Inch
Catalog Description: 3M SCOTCHLOK 40100 2 HOLE COMPRESSION LUG IS SUITABLE FOR USE WITH COPPER OR ALUMINUM CONDUCTORS. THE LUG HAS A STANDARD BARREL THAT ENSURES A SECURE FIT. ALUMINUM CONSTRUCTION OFFERS HIGH CONDUCTIVITY AND AN ELECTRO TIN PLATED FINISH RESISTS CORROSION. IT IS RATED FOR 35 KV VOLTAGE APPLICATIONS.
Category: Large Terminals & Connectors
Full Technical Description: Aluminum Material; Dark Blue Color; 6.56 Inch Overall Length; 2.25 Inch Barrel Length; Aluminum/Copper Conductor Material; UL Approval; 35 kV Voltage Rating; 300 kcmil Conductor Size; 1/2 Inch Stud Size; 251/470 Die Index; 3.56 Inch L X 1.38 Inch W Pad Size; 2 Pad Hole(S); 1.75 Inch Pad Hole Spacing; Standard Barrel Type; Inside Diameter 0.65 Inch; Outside Diameter 1 Inch; Used on Aluminum/Copper Conductor; Application Indoor, Outdoor; Operating Temperature 90 Deg C; 40000 Model
