3M 40178 Scotchlok Aluminum 2-Hole Lug, Up To 35 Kv, 1000 Kcmil, Brown
Product Specifications
UPC: 05400713715
Pad Size: 3.62 Inch L x 2.44 Inch W
Number Of Pad Holes: 2
Pad Hole Spacing: 1.75 Inch
Stud Size: 1/2 Inch
Color: Brown
Die Index: 292/302/319/352
Material: Aluminum
Overall Length: 9.68 Inch
Approval: UL
Additional Information: Inside Diameter 1.19 Inch; Outside Diameter 1.84 Inch; Used On Aluminum/Copper Conductor; Application Indoor, Outdoor; Operating Temperature 90 Deg C
Catalog Number: 40178
Brand Name: Scotchlok[TM]
Model: 40000
Voltage Rating: 35 KV
Conductor Material: Aluminum/Copper
Conductor Size: 1000 KCMIL
Barrel Type: Standard
Barrel Length: 4.62 Inch
Catalog Description: 3M SCOTCHLOK 40100 2 HOLE COMPRESSION LUG IS SUITABLE FOR USE WITH COPPER OR ALUMINUM CONDUCTORS. THE LUG HAS A STANDARD BARREL THAT ENSURES A SECURE FIT. ALUMINUM CONSTRUCTION OFFERS HIGH CONDUCTIVITY AND AN ELECTRO TIN PLATED FINISH RESISTS CORROSION. IT IS RATED FOR 35 KV VOLTAGE APPLICATIONS.
Category: Large Terminals & Connectors
Full Technical Description: Aluminum Material; Brown Color; 9.68 Inch Overall Length; 4.62 Inch Barrel Length; Aluminum/Copper Conductor Material; UL Approval; 35 kV Voltage Rating; 1000 kcmil Conductor Size; 1/2 Inch Stud Size; 292/302/319/352 Die Index; 3.62 Inch L X 2.44 Inch W Pad Size; 2 Pad Hole(S); 1.75 Inch Pad Hole Spacing; Standard Barrel Type; Inside Diameter 1.19 Inch; Outside Diameter 1.84 Inch; Used on Aluminum/Copper Conductor; Application Indoor, Outdoor; Operating Temperature 90 Deg C; 40000 Model
