3M MC2-BCX Scotchlok Large Gauge Butt Connector, 2 Awg, Max. Temp. 347 F (175 C)

Overview

3M MC2-BCX Scotchlok Large Gauge Butt Connector, 2 Awg, Max. Temp. 347 F (175 C)

Product Specifications

• UPC: 05400709205
• Material: ETP Copper
• Temperature Rating: 347 Deg F
• Standard Package: 10 per Carton, 100 per Case
• Approval: UL 486-C, CSA 22.2
• Additional Information: Barrel Style Seamless; Constructional Feature Corrosion Resistance
• Catalog Number: MC2-BCX
• Brand Name: Scotchlok[TM]
• Model: MC2
• Type: Butt
• Length: 1.35 Inch
• Barrel Inner Diameter: 0.341 Inch
• Conductor Size: 2 AWG
• Insulation Type: Non-Insulated
• Catalog Description: 3M SCOTCHLOK LARGE GAUGE COMPRESSION BUTT CONNECTOR ENSURES AN IDEAL FIT WHILE OFFERING RELIABLE AND SAFE PERFORMANCE. THE CONNECTOR HAS A NON-INSULATED, SEAMLESS BARREL AND WITHSTANDS A MAXIMUM TEMPERATURE OF 347 DEGREES F (175 DEGREES C). ELECTROLYTIC COPPER CONSTRUCTION OFFERS GOOD CONDUCTIVITY AND A TIN-PLATED FINISH RESISTS CORROSION.
• Category: Small Terminals & Connectors
• Full Technical Description: Butt Type; Etp Copper Material; 1.35 Inch; UL 486-C, CSA 22.2 Approval; 347 Deg F Temperature Rating; 10 Per Carton, 100 Per Case Standard Package; 2 AWG Conductor Size; Non-Insulated Insulation Type; 0.341 Inch Barrel Inner Diameter; SCOTCHLOK[TM] Brand; Barrel Style Seamless; Constructional Feature Corrosion Resistance; MC2 Model
• Made In Usa: Yes
• Manufacturer: 3M Co.
• Manufacturer Brand: 3M Electrical Products
• Sub Category: Splice Connector
• Unspsc: 39120000
• UPC 12 Digit: 054007092056
• SKU Name: 3m mc2bcx
