3M MV10-8FLK Scotchlok Locking Fork, Vinyl Insulated Brazed Seam, Stud Size 8,

Overview

3M MV10-8FLK Scotchlok Locking Fork, Vinyl Insulated Brazed Seam, Stud Size 8,

Product Specifications

• UPC: 05400713956
• Stud Size: #8
• Temperature Rating: -40 to 221 Deg F
• Standard Package: 500 per Case
• Approval: UL 486A, CSA C22.2
• Additional Information: Overall Dimension 1.03 Inch L x 0.32 Inch W x 0.04 Inch Thk; Voltage Rating 600 V (Building Wire), 1000 V (Signs, Fixtures); Terminal Material Tin Plated ETP Copper; Barrel Style Brazed Seam
• Catalog Number: MV10-8FLK
• Brand Name: Scotchlok[TM]
• Model: MV10
• Type: Locking
• Minimum Conductor Size: 12 AWG
• Maximum Conductor Size: 10 AWG
• Color: Yellow
• Insulation Type: Vinyl Insulated
• Catalog Description: 3M SCOTCHLOK COLOR-CODED LOCKING FORK IS A LUG CONNECTION TERMINAL THAT HAS A SPRING-LIKE TONGUE TO SECURELY LOCK AROUND THE STUD. THE TERMINAL HAS A VINYL-INSULATED, BRAZED-SEAM BARREL AND WITHSTANDS TEMPERATURES OF -40 TO 221 DEGREES F (-40 TO 105 DEGREES C). ELECTROLYTIC COPPER CONSTRUCTION OFFERS GOOD CONDUCTIVITY AND A TIN-PLATED FINISH RESISTS CORROSION.
• Category: Small Terminals & Connectors
• Full Technical Description: Locking Type; Yellow Color; 12 AWG min. Conductor Size; 10 AWG Max. Conductor Size; UL 486A, CSA C22.2 Approval; -40 to 221 Deg F Temperature Rating; 500 Per Case Standard Package; #8 Stud Size; Vinyl Insulated Insulation Type; Overall Dimension 1.03 Inch L X 0.32 Inch W X 0.04 Inch Thk; Voltage Rating 600 V (Building Wire), 1000 V (Signs, Fixtures); Terminal Material Tin Plated Etp Copper; Barrel Style Brazed Seam; MV10 Model
• Made In Usa: Yes
• Manufacturer: 3M Co.
• Manufacturer Brand: 3M Electrical Products
• Sub Category: Fork Lug
• Unspsc: 31201502
• UPC 12 Digit: 054007139560
• SKU Name: 3m mv108flk
