Additional Information: Overall Dimension 0.9 Inch L x 0.33 Inch W x 0.03 Inch Thk; Voltage Rating 600 V (Building Wire), 1000 V (Signs, Fixtures); Terminal Material Tin Plated ETP Copper; Barrel Style Butted Seam
Catalog Number: MVU14-8RK
Brand Name: Scotchlok[TM]
Model: MVU14
Type: Standard
Minimum Conductor Size: 16 AWG
Maximum Conductor Size: 14 AWG
Color: Blue
Insulation Type: Vinyl Insulated
Catalog Description: 3M SCOTCHLOK COLOR-CODED RING TONGUE TERMINAL ENSURES AN IDEAL FIT WHILE OFFERING RELIABLE AND SAFE PERFORMANCE. THE TERMINAL HAS A VINYL-INSULATED, BUTTED-SEAM BARREL AND WITHSTANDS TEMPERATURES OF -40 TO 221 DEGREES F (-40 TO 105 DEGREES C). ELECTROLYTIC COPPER CONSTRUCTION OFFERS GOOD CONDUCTIVITY AND A TIN-PLATED FINISH RESISTS CORROSION.
Category: Small Terminals & Connectors
Full Technical Description: Standard Type; Blue Color; 16 AWG min. Conductor Size; 14 AWG Max. Conductor Size; UL 486A, CSA C22.2 Approval; -40 to 221 Deg F Temperature Rating; 1000 Per Case Standard Package; #8 Stud Size; Vinyl Insulated Insulation Type; Overall Dimension 0.9 Inch L X 0.33 Inch W X 0.03 Inch Thk; Voltage Rating 600 V (Building Wire), 1000 V (Signs, Fixtures); Terminal Material Tin Plated Etp Copper; Barrel Style Butted Seam; MVU14 Model
