Appleton FDC150A 1-Gang Aluminum FDC Box

Overview

Appleton FDC150A 1-Gang Aluminum FDC Box

Product Specifications

• UPC: 78138145577
• Number Of Hubs: 2
• Hub Location: (1) Each End
• Hub Size: 1/2 Inch
• Material: Epoxy Powder Coated Copper Free Aluminum
• Shape: Deep
• Configuration Type: FDC
• Mounting Hardware: Not Included
• Approval: UL 514A
• Additional Information: Application Indoor/Outdoor
• Catalog Number: FDC150A
• Brand Name: Unilet[R]
• Model: FD
• Height: 5.88 Inch
• Width: 2.81 Inch
• Depth: 2.69 Inch
• Capacity: 25 Cu Inch
• Number Of Gangs: 1
• Catalog Description: UNILETS FDC DEEP DEPTH 1-GANG CAST DEVICE BOX, NUMBER OF OUTLET: 2, MATERIAL: COPPERFREE (4/10 OF 1 PCT MAXIMUM) ALUMINUM, SIZE: 1/2 IN, CABLE ENTRY: (2) 1/2 IN HUB, CUBIC CAPACITY: 25 CU-IN, KNOCKOUTS: NO, HEIGHT: 4.56 IN, WIDTH: 2.81 IN, DEPTH: 2.69 IN, FINISH: EPOXY POWDER COAT, STANDARD: UL 514 A, UL FILE NUMBER E2527, CSA C22.2 NO. 18.1, CSA 001472 CERTIFIED, NEMA FB-1, FOR USE WITH THREADED METAL CONDUIT AND IMC
• Category: Aluminum Fs&Fd Type Boxes & Covers
• Full Technical Description: Epoxy Powder Coated Aluminum Material; 2.81 Inch; 5.88 Inch; 2.69 Inch; Deep Shape; 1/2 Inch Hub Size; 2 Hub(S); 1 Gang(S); UL 514A Approval; 25 Cubic Inch Capacity; Not Included Mounting Hardware; Fdc Configuration Type; Includes Stainless Steel Screw; Used on Imc/Rigid Metal Conduit; Application Commercial/Industrial, Switch and Receptacle, Special Conduit Entrance Arrangement; Applicable Standard Nec/Cec, NEMA FB-1; FD Model
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Cast Device Box
• Unspsc: 39121315
• UPC 12 Digit: 781381455770
• SKU Name: app fdc150a
