Appleton L67 2 FM7 Body

Overview

Appleton L67 2 FM7 Body

Product Specifications

• UPC: 78138150667
• Size: 8.13 INCH L X 4.13 INCH W
• Installation: THREADED
• Material: ELECTRO ZINC PLATED DICHROMATE EPOXY POWDER COATED GRAY IRON ALLOY BODY, NEOPRENE GASKET, STAINLESS STEEL COVER SCREW
• Form Type: FORM 7
• Used On: IMC/RIGID CONDUIT
• Additional Information: FEDERAL SPECIFICATION W-C-586B
• Catalog Number: L67
• Brand Name: Unilet.
• Access Opening: RIGHT/LEFT SIDE
• Configuration: L
• Cover Type: ELECTRO ZINC PLATED DICHROMATE EPOXY POWDER COATED CAST GRAY IRON ALLOY
• Hub Location: 90 DEG
• Number Of Hubs: 2
• Hub Size: 2 INCH
• Catalog Description: IMC/RIGID CONDUIT BODY, ACCESS OPENING LEFT/RIGHT SIDE, CONFIGURATION L, COVER TYPE ZINC ELECTROPLATED CHROMATE EPOXY POWDER COATED GRAY IRON, HUB LOCATION 90 DEG, NUMBER OF HUBS 2, HUB SIZE 2 INCH, SIZE 8.13 INCH L X 4.06 INCH W, INSTALLATION THREADED, MATERIAL ZINC ELECTROPLATED CHROMATE EPOXY POWDER COATED GRAY IRON BODY, NEOPRENE GASKET, STAINLESS STEEL SCREW, FORM TYPE FORM 7, APPROVAL UL 514A/514B/E2527, CSA C22.2, USED ON IMC/RIGID CONDUIT, APPLICABLE STANDARD NEC/CEC, NEMA FB-1, CAPACITY 50 CU INCH
• Category: Steel Conduit Bodies & Covers
• Full Technical Description: Zinc Electroplated/Chromate/Epoxy Powder Coated Grayloy-Iron (Body), Stainless Steel (Cover Screw) Material; 8.13 Inch Length X 4.06 Inch Width Size; Imc/Rigid Conduit Used on; 2 Inch Hub Size; Threaded Installation; L Configuration; 2 Hub(S); UL 514A/B, CSA C22.2 Approval; Zinc Electroplated Steel Cover Type; 90 Degree Hub Location; Form 7 Form Type; Side Access Opening; FM7[TM] Brand; Wire Size (3) 2 AWG; Capacity 50 Cubic Inch; Enclosure Rating Class I Div 2; Application Commercial/Industrial, Hazardous/Wet Location; Applicable Standard Nec/Cec, NEMA FB-1
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Conduit Body
• Unspsc: 39131708
• UPC 12 Digit: 781381506670
• SKU Name: app l67

Resources

• Manufacturer Spec Sheet
