Blackburn CSP6 6Str Copper Compression Splice

Overview

Blackburn CSP6 6Str Copper Compression Splice

Product Specifications

• UPC: 78378613204
• Body Material: Seamless Tin Plated High Conductivity Copper
• Approval: UL, CSA
• Additional Information: Constructional Feature Corrosion Resistance
• Catalog Number: CSP6
• Model: CSP
• Voltage Rating: 35 KV
• Conductor Size: 6 AWG Stranded
• Conductor Material: Copper
• Color Code: Blue
• Barrel Type: Short with Chamfered End
• Length: 1 Inch
• Catalog Description: TYPE CSP COPPER SPLICE, SHORT BARREL, MAX 35KV, WIRE SIZE 6 STR, TIN PLATED, DIE COLOR CODE BLUE
• Category: Large Terminals & Connectors
• Full Technical Description: 1 Inch; Copper Conductor Material; UL, CSA Approval; 35 kV Voltage Rating; Seamless Tin Plated High Conductivity Copper Body Material; 6 AWG Stranded Conductor Size; Blue Color Code; Short With Chamfered End Barrel Type; Constructional Feature Corrosion Resistance; CSP Model
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Blackburn
• Sub Category: Compression Cable Splice
• Unspsc: 39121449
• UPC 12 Digit: 783786132041
• SKU Name: csp6 blackburn
