Blackburn CTL30-12 Copper Test Point 1-Hole Lug Short Barrel 3/0 1/2B Orange
Product Specifications
UPC: 78378613187
Number Of Pad Holes: 1
Stud Size: 1/2 Inch
Color: Orange
Material: Tin Plated Seamless Copper
Overall Length: 2-11/32 Inch
Approval: UL, CSA
Catalog Number: CTL30-12
Model: CTL
Voltage Rating: 35 Kilovolt
Conductor Material: Copper
Conductor Size: 3/0 AWG Stranded
Barrel Type: Short, Standard, Straight
Barrel Length: 13/16 Inch
Pad Size: 1-1/4 Inch Length x 29/32 Inch Width x 1/8 Inch Thickness
Catalog Description: COPPER ONE-HOLE LUG, SHORT BARREL, MAX 35KV, 3/0 STR. WIRE, 1/2 BOLT SIZE, TIN PLATED, DIE COLOR CODE ORANGE
Category: Large Terminals & Connectors
Full Technical Description: Tin Plated Seamless Copper Material; Orange Color; 2-11/32 Inch Overall Length; 13/16 Inch Barrel Length; Copper Conductor Material; UL, CSA Approval; 35 Kilovolt Voltage Rating; 3/0 AWG Stranded Conductor Size; 1/2 Inch Stud Size; 1-1/4 Inch Length X 29/32 Inch Width X 1/8 Inch Thickness Pad Size; 1 Pad Hole(S); Short, Standard, Straight Barrel Type; CTL Model
