Blackburn CTL500L-58 Copper Test Point 1-Hole Lug Long Barrel 500 5/8B Brown

Overview

Blackburn CTL500L-58 Copper Test Point 1-Hole Lug Long Barrel 500 5/8B Brown

Product Specifications

• UPC: 78378641044
• Number Of Pad Holes: 1
• Stud Size: 5/8 Inch
• Color: Brown
• Die Index: 33, 87H
• Material: Tin Plated Seamless Copper
• Overall Length: 4-1/2 Inch
• Approval: UL, CSA
• Additional Information: Application Industrial, Oil Rig, Mining, Welding, Transportation Electrical Termination
• Catalog Number: CTL500L-58
• Model: CTL
• Voltage Rating: 35 KV
• Conductor Material: Copper
• Conductor Size: 500 KCMIL, 5/8 (Flex), 925/24 Stranded
• Barrel Type: Long, Straight
• Barrel Length: 2-11/32 Inch
• Pad Size: 1-9/16 Inch L x 1-19/32 Inch W x 3/16 Inch Thk
• Catalog Description: COPPER ONE-HOLE LUG, LONG BARREL, MAX 35KV, 500 KCMIL WIRE, 5/8 BOLT SIZE, TIN PLATED, DIE COLOR CODE BROWN
• Category: Large Terminals & Connectors
• Full Technical Description: Tin Plated Seamless Copper Material; Brown Color; 4-1/2 Inch Overall Length; 2-11/32 Inch Barrel Length; Copper Conductor Material; UL, CSA Approval; 35 kV Voltage Rating; 500 kcmil, 5/8 (Flex), 925/24 Stranded Conductor Size; 5/8 Inch Stud Size; 33, 87H Die Index; 1-9/16 Inch L X 1-19/32 Inch W X 3/16 Inch Thk Pad Size; 1 Pad Hole(S); Long, Straight Barrel Type; Application Industrial, Oil Rig, Mining, Welding, Transportation Electrical Termination; CTL Model
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Blackburn
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 783786410446
• SKU Name: ctl500l58 blackburn
