Blackburn CU20 Copper Test Point Splice Long Barrel 2/0Str Black

Overview

Blackburn CU20 Copper Test Point Splice Long Barrel 2/0Str Black

Product Specifications

• UPC: 78378613220
• Body Material: Seamless Tin Plated High Conductivity Copper
• Approval: UL, CSA
• Additional Information: Constructional Feature Corrosion Resistant; Application Industrial, Oil Rig, Mining, Welding and Transportation Electrical Termination
• Catalog Number: CU20
• Model: CU
• Voltage Rating: 35 KV
• Conductor Size: 2/0 AWG Stranded, 1/0 AWG (CMA Flex), 275/24 Stranded (Flex)
• Conductor Material: Copper
• Color Code: Black
• Barrel Type: Long with Chamfered End
• Length: 2-1/8 Inch
• Catalog Description: TYPE CU COPPER SPLICE, LONG BARREL, 2-1/8 INCH LENGTH, MAX 35KV, WIRE SIZE 2/0 STR, TIN PLATED, DIE COLOR CODE BLACK
• Category: Large Terminals & Connectors
• Full Technical Description: 2-1/8 Inch; Copper Conductor Material; UL, CSA Approval; 35 kV Voltage Rating; Seamless Tin Plated High Conductivity Copper Body Material; 2/0 AWG Stranded, 1/0 AWG (CMA Flex), 275/24 Stranded (Flex) Conductor Size; Black Color Code; Long With Chamfered End Barrel Type; Constructional Feature Corrosion Resistant; Application Industrial, Oil Rig, Mining, Welding and Transportation Electrical Termination; CU Model
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Blackburn
• Sub Category: Compression Cable Splice
• Unspsc: 39121449
• UPC 12 Digit: 783786132201
• SKU Name: cu20 blkbrn
