Catalog Description: OZ-GEDNEY NON-WATERTIGHT CONNECTOR, SIZE: 3/4 IN, CONNECTION: MALE NPS HUB X SET SCREW, CONDUCTOR RANGE: 0.37 - 0.84 IN, MALLEABLE IRON, FINISH: ZINC ELECTROPLATED, DIMENSIONS: 1-13/16 IN DIAMETER X 0.84 IN WIDTH, 11/16 IN THREAD LENGTH, 7/16 IN HUB TURNING, THIRD PARTY CERTIFICATION: UL FILE NUMBER E-11856 (SE CABLES), UL FILE NUMBER E-11858 (NM AND SE CABLES), CSA 11584 (NM CABLE), APPLICABLE THIRD PARTY STANDARDS: UL 514B, CSA C22.2 NO.18, FEDERAL SPECIFICATION W-F-406E, FOR SECURING SEU AND OTHER ROUND NON-METALLIC CABLES TO BOXES AND ENCLOSURES IN DRY LOCATIONS
Category: Non-Metallic Cable Cable Fittings
Full Technical Description: Zinc Plated Malleable Iron Material; 2 Screw Clamp Installation; Non-Metallic Sheathed Cable/Armored Cable/Flexible Cable/Metal Clad Cable Cable Type; 0.37 to 0.84 Inch Cable Size; UL 514B, CSA C22.2 Approval; 3/4 Inch Trade Size; Insulated Throat Type; Includes Locknut; Clamping Range 0.37 to 0.84 Inch; Overall Dimension 1-13/16 Inch W X 18/16 Inch H; 806 Model
Manufacturer: O-Z Gedney
Manufacturer Brand: O-Z Gedney
Sub Category: Nonmetallic Sheathed Cable Connector
