OZ-Gedney ECGJH-75-4 3/4X4 Flex Coupling

Overview

OZ-Gedney ECGJH-75-4 3/4X4 Flex Coupling

Product Specifications

• UPC: 78312611651
• Approval: UL 886, CSA C22.2
• Additional Information: Includes Insulating Liner; Maximum Temperature Rating 300 Deg F; Constructional Feature Watertight
• Catalog Number: ECGJH-75-4
• Model: ECGJH
• Trade Size: 3/4 Inch
• Fitting Material: Bronze End, Steel Nipple
• Material: Bronze Braid, Brass Tube
• End Type: (2) Threaded Nipple
• Length: 4 Inch
• Enclosure: Class I Div 1 and 2 Group A B C D, Class I Zone 1 and 2 Group IIA IIB IIC, Class II Div 1 and 2 Group E F G, Class III
• Catalog Description: FLEXIBLE CONDUIT COUPLING, TRADE SIZE 3/4 INCH, FITTING MATERIAL BRONZE END, STEEL NIPPLE, MATERIAL BRONZE BRAID, BRASS TUBE, END TYPE (2) FEMALE THREADED NIPPLE, LENGTH 4 INCH, ENCLOSURE CLASS I DIV 1 AND 2 GROUP A B C D, CLASS I ZONE 1 AND 2 GROUP IIA IIB IIC, CLASS II DIV 1 AND 2 GROUP E F G, CLASS III, APPROVAL UL 886, CSA C22.2, APPLICABLE STANDARD NEC, APPLICATION HAZARDOUS LOCATION, MAXIMUM TEMPERATURE RATING 300 DEG F, INCLUDES INSULATING LINER, REMOVABLE CLOSE NIPPLE
• Category: Rigid Conduit Fittings - Steel
• Full Technical Description: Bronze Braid, Brass Tube Material; 4 Inch; UL 886, CSA C22.2 Approval; Class I Div 1 and 2 Group A B C D, Class I Zone 1 and 2 Group Iia Iib Iic, Class II Div 1 and 2 Group E F G, Class III Enclosure; 3/4 Inch Trade Size; (2) Threaded Nipple End Type; Bronze End, Steel Nipple Fitting Material; Includes Insulating Liner; Maximum Temperature Rating 300 Deg F; Constructional Feature Watertight; ECGJH Model
• Manufacturer: O-Z Gedney
• Manufacturer Brand: O-Z Gedney
• Sub Category: Explosionproof Flexible Conduit Coupling
• Unspsc: 39131707
• UPC 12 Digit: 783126116519
• SKU Name: ozg ecgjh754

Resources

• Manufacturer Spec Sheet
