Panduit PV10-10R-D Ring Terminal Vinyl 12-10Awg #10 Pk500
Product Specifications
UPC: 07498380133
Stud Size: #10
Temperature Rating: 221 Deg F
Standard Package: 500 per Pack
Approval: UL 486A/B, UL (Canada and US), CSA C22.2
Additional Information: RoHS Compliant; Barrel Type Brazed Seam; Voltage Rating 600 Volt; Material Electrolytic Tin Plated Copper; Overall Dimension 1.05 Inch Length x 0.31 Inch Width; Flammability Rating UL 94 V-0
Catalog Number: PV10-10R-D
Brand Name: Panduit
Model: PV-R
Type: Funnel Entry
Minimum Conductor Size: 12 AWG
Maximum Conductor Size: 10 AWG
Color: Yellow
Insulation Type: Vinyl Insulated
Catalog Description: THE PV10-10R-D PAN-TERM TERMINAL IS A VINYL INSULATED, RING TERMINAL. BRAZED SEAM PROTECTS TERMINAL BARREL FROM SPLITTING DURING THE CRIMP PROCESS. INTERNAL BARREL SERRATIONS ASSURE GOOD WIRE CONTACT AND MAXIMUM TENSILE STRENGTH. EXTENTED BARREL INSULATION PROVIDES PROTECTION AND STRAIN RELIEF WHEN CRIMPED.
Category: Small Terminals & Connectors
Full Technical Description: Funnel Entry Type; Yellow Color; 12 AWG min. Conductor Size; 10 AWG Max. Conductor Size; UL 486A/B, UL (Canada and Us), CSA C22.2 Approval; 221 Deg F Temperature Rating; 500 Per Pack Standard Package; #10 Stud Size; Vinyl Insulated Insulation Type; PAN-TERM[R] Brand; RoHS Compliant; Barrel Type Brazed Seam; Voltage Rating 600 Volt; Material Electrolytic Tin Plated Copper; Overall Dimension 1.05 Inch Length X 0.31 Inch Width; Flammability Rating UL 94 V-0; PV-R Model
