Panduit PV14-10R-M Ring Terminal Vinyl 16-14Awg #10 Pk1000

Overview

Panduit PV14-10R-M Ring Terminal Vinyl 16-14Awg #10 Pk1000

Product Specifications

• UPC: 07498380121
• Stud Size: #10
• Temperature Rating: 221 Deg F
• Standard Package: 10000 per Pack
• Approval: UL 486A/B, UL (Canada and US), CSA C22.2
• Additional Information: RoHS Compliant; Barrel Type Brazed Seam; Voltage Rating 600 Volt; Material Electrolytic Tin Plated Copper; Overall Dimension 0.92 Inch Length x 0.31 Inch Width; Flammability Rating UL 94 V-0
• Catalog Number: PV14-10R-M
• Brand Name: Panduit
• Model: PV-R
• Type: Funnel Entry
• Minimum Conductor Size: 16 AWG
• Maximum Conductor Size: 14 AWG
• Color: Blue
• Insulation Type: Vinyl Insulated
• Catalog Description: THE PV14-10R-M PAN-TERM TERMINAL IS A VINYL INSULATED, RING TERMINAL. BRAZED SEAM PROTECTS TERMINAL BARREL FROM SPLITTING DURING THE CRIMP PROCESS. INTERNAL BARREL SERRATIONS ASSURE GOOD WIRE CONTACT AND MAXIMUM TENSILE STRENGTH. EXTENTED BARREL INSULATION PROVIDES PROTECTION AND STRAIN RELIEF WHEN CRIMPED.
• Category: Small Terminals & Connectors
• Full Technical Description: Funnel Entry Type; Blue Color; 16 AWG min. Conductor Size; 14 AWG Max. Conductor Size; UL 486A/B, UL (Canada and Us), CSA C22.2 Approval; 221 Deg F Temperature Rating; 10000 Per Pack Standard Package; #10 Stud Size; Vinyl Insulated Insulation Type; PAN-TERM[R] Brand; RoHS Compliant; Barrel Type Brazed Seam; Voltage Rating 600 Volt; Material Electrolytic Tin Plated Copper; Overall Dimension 0.92 Inch Length X 0.31 Inch Width; Flammability Rating UL 94 V-0; PV-R Model
• Manufacturer: PANDUIT CORPORATION
• Sub Category: Ring Lug
• Unspsc: 39121409
• UPC 12 Digit: 074983801213
• SKU Name: pand pv1410rm
