T&B 60516 Copper Tin Plated 2-Way Connector Splice Standard 2-3 Pink

Overview

T&B 60516 Copper Tin Plated 2-Way Connector Splice Standard 2-3 Pink

Product Specifications

• UPC: 78621060516
• Length: 1.81 Inch
• Outer Diameter: 0.51 Inch
• Body Material: Electro Tin Plated Wrought Aluminum
• Approval: UL, CSA
• Additional Information: Die Code 42; Temperature Rating 90 Deg C
• Catalog Number: 60516
• Brand Name: Blackburn
• Type: 2-Way
• Voltage Rating: 600 Volt to 35 Kilovolt
• Conductor Size: 2 or 3 AWG Stranded (Code)
• Conductor Material: Aluminum/Copper
• Color Code: Pink
• Barrel Type: Standard
• Catalog Description: TWO-WAY ALUMINUM SPLICE CONNECTOR, WIRE SIZE 2 STR/3 STR, DIE CODE 42, DIE COLOR CODE PINK
• Category: Large Terminals & Connectors
• Full Technical Description: 2-Way Type; 1.81 Inch; 0.51 Inch Outer Diameter; Aluminum/Copper Conductor Material; UL, CSA Approval; 600 Volt to 35 Kilovolt Voltage Rating; Electro Tin Plated Wrought Aluminum Body Material; 2 or 3 AWG Stranded (Code) Conductor Size; Pink Color Code; Standard Barrel Type; Die Code 42; Temperature Rating 90 Deg C
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Compression Cable Splice
• Unspsc: 39121449
• UPC 12 Digit: 786210605166
• SKU Name: t&b 60516
