3M 10010 Scotchlok Copper Standard Barrel Connector, Up To 35 Kv, 300 Kcmil, White

Overview

3M 10010 Scotchlok Copper Standard Barrel Connector, Up To 35 Kv, 300 Kcmil, White

Product Specifications

• UPC: 05400712857
• Barrel Type: STANDARD BARREL
• Length: 2.25 INCH
• Length In Inch: 2.25
• Inner Diameter: 0.65 INCH
• Outer Diameter: 0.813 INCH
• Body Material: COPPER
• Approval: UL 486-A, UL 486-B, CSA
• Additional Information: PACKAGING QUANTITY 3 PER CASE; APPLICATION INDOOR/OUTDOOR
• Catalog Number: 10010
• Brand Name: Scotchlok[T]
• Model: 10000
• Type: CENTER WIRE STOP
• Voltage Rating: 35 KV
• Conductor Size: 300 KCMIL
• Conductor Material: COPPER
• Color Code: WHITE
• Catalog Description: THEY ARE DESIGNED TO CONNECT COPPER CONDUCTORS. EACH CONNECTOR IS ELECTRO-TIN PLATED TO RESIST ELECTROLYTIC CORROSION. THEY ARE INSTALLED USING STANDARD INDUSTRY TOOLING. CHAMFERED ENDS AND AN INTEGRAL CENTER CABLE STOP ENSURE SIMPLICITY AND EASE OF CONDUCTOR INSERTION.
• Category: Large Terminals & Connectors
• Full Technical Description: Center Wire Stop Type; 2.25 Inch; 2.25 Length in Inch; 0.65 Inch Inner Diameter; 0.813 Inch Outer Diameter; Copper Conductor Material; UL 486-A, UL 486-B, CSA Approval; 35 kV Voltage Rating; Copper Body Material; 300 kcmil Conductor Size; White Color Code; Standard Barrel Barrel Type; SCOTCHLOK[T] Brand; Packaging Quantity 3 Per Case; Application Indoor/Outdoor; 10000 Model
• Manufacturer: 3M Co.
• Manufacturer Brand: 3M Electrical Products
• Sub Category: Compression Cable Splice
• Unspsc: 27121707
• UPC 12 Digit: 054007128571
• SKU Name: 3m 10010
