3M 11009 Scotchlok Copper Long-Barrel Connector, Up To 35 Kv, 250 Kcmil, Yellow

Overview

3M 11009 Scotchlok Copper Long-Barrel Connector, Up To 35 Kv, 250 Kcmil, Yellow

Product Specifications

• UPC: 05400712840
• Length: 3.38 Inch
• Inner Diameter: 0.6 Inch
• Outer Diameter: 0.75 Inch
• Body Material: Electro Tin Plated Copper
• Approval: UL, CSA
• Additional Information: RoHS Compliant; Applicable Standard ANSI
• Catalog Number: 11009
• Brand Name: Scotchlok[TM]
• Model: 11000
• Voltage Rating: 35 Kilovolt
• Conductor Size: 250 KCMIL
• Conductor Material: Copper
• Color Code: Yellow
• Barrel Type: Long
• Catalog Description: THE 3M SCOTCHLOK CONNECTORS 20000 SERIES CAN BE USED WITH EITHER COPPER OR ALUMINUM CONDUCTORS. THESE ALUMINUM CONNECTORS FEATURE COLOR CODED END CAPS FOR IDENTIFICATION. CONTACT AID PROVIDED IN CONNECTOR IS COMPATIBLE WITH POLY/EPR INSULATIONS. EACH CONNECTOR IS ELECTRO TIN PLATED TO RESIST ELECTROLYTIC CORROSION, AND HAVE A SOLID CENTER STOP. (UL 486B LISTED)
• Category: Large Terminals & Connectors
• Full Technical Description: 3.38 Inch; 0.6 Inch Inner Diameter; 0.75 Inch Outer Diameter; Copper Conductor Material; UL, CSA Approval; 35 Kilovolt Voltage Rating; Electro Tin Plated Copper Body Material; 250 kcmil Conductor Size; Yellow Color Code; Long Barrel Type; RoHS Compliant; Applicable Standard ANSI; 11000 Model
• Manufacturer: 3M Co.
• Manufacturer Brand: 3M Electrical Products
• Sub Category: Compression Cable Splice
• Unspsc: 27121707
• UPC 12 Digit: 054007128403
• SKU Name: 3m 11009
