T&B 54813 2-Way Copper Splice Connector Long Barrel 250 Yellow

Overview

T&B 54813 2-Way Copper Splice Connector Long Barrel 250 Yellow

Product Specifications

• UPC: 78621054813
• Length: 3.38 Inch
• Outer Diameter: 0.79 Inch
• Body Material: Electro Tin Plated Wrot Copper
• Approval: UL, CSA
• Additional Information: Die Code 62; Strip Length 1-9/16 Inch
• Catalog Number: 54813
• Brand Name: Blackburn/Color-Keyed
• Type: 2-Way
• Voltage Rating: 600 Volt to 35 Kilovolt
• Conductor Size: 250 KCMIL (Code), 222 KCMIL (550/24 Flex)
• Conductor Material: Copper
• Color Code: Yellow
• Barrel Type: Long
• Catalog Description: COPPER TWO-WAY SPLICE, LONG BARREL, 35KV MAX, WIRE SIZE 250 KCMIL, 550/24, LENGTH 3.38 INCHES (85.85MM), TIN PLATED, DIE CODE 62, DIE COLOR CODE YELLOW
• Category: Large Terminals & Connectors
• Full Technical Description: 2-Way Type; 3.38 Inch; 0.79 Inch Outer Diameter; Copper Conductor Material; UL, CSA Approval; 600 Volt to 35 Kilovolt Voltage Rating; Electro Tin Plated Wrot Copper Body Material; 250 kcmil (Code), 222 kcmil (550/24 Flex) Conductor Size; Yellow Color Code; Long Barrel Type; Die Code 62; Strip Length 1-9/16 Inch
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Compression Cable Splice
• Unspsc: 39121449
• UPC 12 Digit: 786210548135
• SKU Name: t&b 54813
