Blackburn CTL302 Copper Test Point 2-Hole Lug Short Barrel 3/0 1/2B Orange

Overview

Blackburn CTL302 Copper Test Point 2-Hole Lug Short Barrel 3/0 1/2B Orange

Product Specifications

• UPC: 78378613125
• Number Of Pad Holes: 2
• Pad Hole Spacing: 1-3/4 Inch
• Stud Size: 1/2 Inch
• Color: Orange
• Die Index: 50
• Material: Tin Plated Seamless Copper
• Overall Length: 3-15/16 Inch
• Approval: UL, CSA
• Additional Information: Application Regular Duty, Conned Area
• Catalog Number: CTL302
• Model: CTL
• Voltage Rating: 35 KV
• Conductor Material: Copper
• Conductor Size: 3/0 AWG Stranded
• Barrel Type: Short, Straight
• Barrel Length: 25/32 Inch
• Pad Size: 2-13/16 Inch L x 15/16 Inch W x 1/8 Inch Thk
• Catalog Description: TYPE CTL COPPER TWO-HOLE LUG, SHORT BARREL, MAX 35KV, WIRE SIZE 3/0 STR OR 2/0 WELD, 1/2 INCH BOLT SIZE, TIN PLATED, DIE COLOR CODE ORANGE
• Category: Large Terminals & Connectors
• Full Technical Description: Tin Plated Seamless Copper Material; Orange Color; 3-15/16 Inch Overall Length; 25/32 Inch Barrel Length; Copper Conductor Material; UL, CSA Approval; 35 kV Voltage Rating; 3/0 AWG Stranded Conductor Size; 1/2 Inch Stud Size; 50 Die Index; 2-13/16 Inch L X 15/16 Inch W X 1/8 Inch Thk Pad Size; 2 Pad Hole(S); 1-3/4 Inch Pad Hole Spacing; Short, Straight Barrel Type; Application Regular Duty, Conned Area; CTL Model
• Manufacturer: THOMAS & BETTS BLACKBURN
• Manufacturer Brand: T&B Blackburn
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 783786131259
• SKU Name: ctl302 blackburn
