Blackburn CTL40-12 Copper Test Point 1-Hole Lug Short Barrel 4/0 1/2B Purple

Overview

Blackburn CTL40-12 Copper Test Point 1-Hole Lug Short Barrel 4/0 1/2B Purple

Product Specifications

• UPC: 78378613189
• Number Of Pad Holes: 1
• Stud Size: 1/2 Inch
• Color: Purple
• Die Index: 54
• Material: Tin Plated Seamless Copper
• Overall Length: 2-1/2 Inch
• Approval: UL, CSA
• Catalog Number: CTL40-12
• Model: CTL
• Voltage Rating: 35 KV
• Conductor Material: Copper
• Conductor Size: 4/0 AWG Stranded, 3/0 AWG (Weld)
• Barrel Type: Short, Straight
• Barrel Length: 15/16 Inch
• Pad Size: 1-1/4 Inch L x 1-1/32 Inch W x 1/8 Inch Thk
• Catalog Description: COPPER ONE-HOLE LUG, SHORT BARREL, MAX 35KV, 4/0 STR. WIRE, 1/2 BOLT SIZE, TIN PLATED, DIE COLOR CODE PURPLE
• Category: Large Terminals & Connectors
• Full Technical Description: Tin Plated Seamless Copper Material; Purple Color; 2-1/2 Inch Overall Length; 15/16 Inch Barrel Length; Copper Conductor Material; UL, CSA Approval; 35 kV Voltage Rating; 4/0 AWG Stranded, 3/0 AWG (Weld) Conductor Size; 1/2 Inch Stud Size; 54 Die Index; 1-1/4 Inch L X 1-1/32 Inch W X 1/8 Inch Thk Pad Size; 1 Pad Hole(S); Short, Straight Barrel Type; CTL Model
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Blackburn
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 783786131891
• SKU Name: ctl4012 blackburn
