OZ-Gedney LB27 3/4" Form 7 Type-LB Unilet

OZ-Gedney LB27 3/4" Form 7 Type-LB Unilet

85 in stock

Regular price $17.31 USD
Regular price Sale price $17.31 USD
Sale Sold out
Quantity

Overview

OZ-Gedney LB27 3/4" Form 7 Type-LB Unilet

Product Specifications

  • UPC: 78312632776
  • Size: 5.19 Inch L x 2.5 Inch H
  • Installation: Threaded
  • Material: Zinc Electroplated/Chromate/Epoxy Powder Coated Gray Iron (Body), Neoprene (Gasket), Stainless Steel Cover (Screw)
  • Form Type: Form 7
  • Approval: UL 514A/514B, CSA C22.2
  • Used On: Rigid/IMC Conduit
  • Additional Information: Applicable Standard NEMA FB-1; Capacity 7 Cu Inch
  • Catalog Number: LB27
  • Brand Name: Unilet[R], FM7[TM]
  • Access Opening: Back
  • Configuration: LB
  • Cover Type: Zinc Electroplated/Chromate/Epoxy Powder Coated Gray Iron
  • Hub Location: 90 Degree
  • Number Of Hubs: 2
  • Hub Size: 3/4 Inch
  • Catalog Description: OZ-GEDNEY TYPE LB CONDUIT BODY, 3/4 IN HUB, FORM: 7, LENGTH: 5-3/16 IN, 1-9/16 IN WIDTH, 2-1/2 IN HEIGHT, IRON, FINISH: ZINC ELECTROPLATED WITH ALUMINUM ENAMEL, GRAY, CONNECTION: TAPERED FNPT, 3 (6 AWG) CONDUCTORS, 6.9 CU-IN VOLUME, THIRD PARTY CERTI
  • Category: Miscellaneous Conduit Bodies
  • Full Technical Description: Zinc Electroplated/Chromate/Epoxy Powder Coated Grayloy Iron Body, Neoprene Gasket, Stainless Steel Cover Screw Material; 5.19 Inch L X 2.44 Inch W X 2.50 Inch H Size; Rigid/Imc Conduit Used on; 3/4 Inch Hub Size; Threaded Installation; lb Configuration; 2 Hub(S); UL, UL 514A, CSA C22.2 Approval; Grayloy Iron, Steel Cover Type; 90 Degree Hub Location; Form 7 Form Type; Back Access Opening; UNILET[R], FM7[TM] Brand; Maximum Wire Fill (3) 6 AWG; Applicable Standard NEMA FB-1/Fb-2.10, Federal Specification A-A-50563
  • Manufacturer: O-Z Gedney
  • Manufacturer Brand: O-Z Gedney
  • Sub Category: Conduit Body
  • Unspsc: 39131708
  • UPC 12 Digit: 783126327762
  • SKU Name: ozg lb27
