OZ-Gedney SR-950-375 1/2" .25-.375 Cord Connector

Overview

OZ-Gedney SR-950-375 1/2" .25-.375 Cord Connector

Product Specifications

• UPC: 78312650690
• Approval: UL, CSA
• Application: Liquidtight, Oiltight, Raintight, Strain Relief, Wet/Hazardous Location
• Additional Information: Color White; Throat Inner Diameter 0.59 Inch; Temperature Rating 90 Deg C
• Catalog Number: SR-950-375
• Brand Name: Grip-Tite[R]
• Model: SR
• Type: 90 Deg Male
• Thread Size: 1/2 Inch
• Material: Zinc Plated Malleable Iron Body/Gland Nut, Neoprene Grommet, Nylon Gripper, PVC/Buna-N Sealing Ring, Zinc Plated Steel Locknut
• Cord Size: 0.25 to 0.375 Inch
• Size: 1-1/8 Inch Dia x 1-3/8 Inch L
• Catalog Description: OZ-GEDNEY TYPE SR GRIP-TITE STRAIN RELIEF 90 DEG CONNECTOR, SIZE: 1/2 IN, CONDUCTOR RANGE: 0.25 - 0.375 IN, MALLEABLE IRON BODY AND GLAND NUT, NYLON GRIPPER, NEOPRENE GROMMET, PVC OR BUNA-N SEALING RING, STEEL LOCKNUT, FINISH: ZINC PLATED BODY,
• Category: Cable & Cord Grips
• Full Technical Description: 90 Deg Male Type; Zinc Plated Malleable Iron Body/Gland Nut, Neoprene Grommet, Nylon Gripper, Pvc/Buna-N Sealing Ring, Zinc Plated Steel Locknut Material; 1-1/8 Inch Dia X 1-3/8 Inch L Size; UL, CSA Approval; Liquidtight, Oiltight, Raintight, Strain Relief, Wet/Hazardous Location Application; 1/2 Inch Thread Size; 0.25 to 0.375 Inch Cord Size; GRIP-TITE[R] Brand; Color White; Throat Inner Diameter 0.59 Inch; Temperature Rating 90 Deg C; SR Model
• Manufacturer: O-Z Gedney
• Manufacturer Brand: O-Z Gedney
• Sub Category: Flexible Cord/Cable Connector
• Unspsc: 39121431
• UPC 12 Digit: 783126506907
• SKU Name: ozg sr950375

Resources

• Manufacturer Spec Sheet
