Panduit SCS500-6 Copper Butt Splice 500Kcmil Pkg 6

Overview

Panduit SCS500-6 Copper Butt Splice 500Kcmil Pkg 6

Product Specifications

• UPC: 07498390365
• Length: 2.87 Inch
• Inner Diameter: 0.84 Inch
• Outer Diameter: 1.05 Inch
• Body Material: Tin Plated Copper
• Approval: UL, CSA
• Additional Information: Temperature Rating 90 Deg C; ROHS Compliant
• Catalog Number: SCS500-6
• Model: SCS
• Type: Butt
• Voltage Rating: 35 KV
• Conductor Size: 500 KCMIL
• Conductor Material: Copper
• Color Code: Brown
• Barrel Type: Standard
• Catalog Description: COPPER BUTT SPLICE, STANDARD BARREL, 500 KCMIL CABLE.
• Category: Large Terminals & Connectors
• Full Technical Description: Butt Type; 2.87 Inch; 0.84 Inch Inner Diameter; 1.05 Inch Outer Diameter; Copper Conductor Material; UL, CSA Approval; 35 kV Voltage Rating; Tin Plated Copper Body Material; 500 kcmil Conductor Size; Brown Color Code; Standard Barrel Type; Pan-LUG[TM] Brand; Temperature Rating 90 Deg C; RoHS Compliant; SCS Model
• Manufacturer: PANDUIT CORPORATION
• Sub Category: Compression Cable Splice
• Unspsc: 39121449
• UPC 12 Digit: 074983903658
• SKU Name: pand scs5006
